In this article I will explain with an example, how to use Custom ASP.Net Server control DropDownCheckBoxes which is a Multiple Selection DropDownList consisting of a CheckBoxList control within it.
This article makes use of DropDownCheckBoxes library for implementing ASP.Net DropDownList CheckBoxList Server control.
Installing DropDownCheckBoxes library from Nuget
First, install the DropDownCheckBoxes library from Nuget Package Manager Console using the following command.
Install-Package DropDownCheckBoxes -Version
DropDownCheckBoxes: ASP.Net DropDownList CheckBoxList Server control
Once the package is installed, a success message will be displayed.
DropDownCheckBoxes: ASP.Net DropDownList CheckBoxList Server control
Note: For more details on how to use Nuget Package Manager Console, please refer the article Install Nuget package in Visual Studio 2012, 2013, 2015.
Registering the DropDownCheckBoxes DLL
After successful installation, you will need to register the control on the page using the Register directive as shown below.
<%@ Register TagPrefix="asp" Namespace="Saplin.Controls" Assembly="DropDownCheckBoxes" %>
HTML Markup
The following HTML Markup consists of DropDownCheckBoxes, an ExtendedRequiredFieldValidator and a Button.
The DropDownCheckBoxes control has been specified with a property UseSelectAllNode, which displays an additional Select All CheckBox when set to TRUE.
The DropDownCheckBoxes will be validated using ExtendedRequiredFieldValidator.
The ExtendedRequiredFieldValidator has been specified with following properties:
ControlToValidate – Specifies the ID of the control to be validated.
Error Message – It has been specified with a string value, which will be displayed to the user when the validation fails.
<asp:DropDownCheckBoxes ID="DropDownCheckBoxes1" runat="server" Width="180px" UseSelectAllNode="false">
    <Style SelectBoxWidth="195" DropDownBoxBoxWidth="160" DropDownBoxBoxHeight="90" />
        <asp:ListItem Text="Mango" Value="1"></asp:ListItem>
        <asp:ListItem Text="Apple" Value="2"></asp:ListItem>
        <asp:ListItem Text="Banana" Value="3"></asp:ListItem>
<asp:ExtendedRequiredFieldValidator ID="ExtendedRequiredFieldValidator1" runat="server"
    ControlToValidate="DropDownCheckBoxes1" ErrorMessage="Required" ForeColor="Red">
<br />
<br />
<asp:Button Text="Submit" runat="server" OnClick="Submit" />
Fetching the selected values on Server Side on Button click
When the Submit Button is clicked, a loop is executed over the Items of the DropDownCheckBoxes control and the selected Items are displayed using JavaScript alert message box.
protected void Submit(object sender, EventArgs e)
    string message = string.Empty;
    foreach (ListItem item in DropDownCheckBoxes1.Items)
        if (item.Selected)
            message += item.Text + " " + item.Value + "\\n";
    ClientScript.RegisterClientScriptBlock(this.GetType(), "alert", "alert('" + message + "');", true);
Protected Sub Submit(sender As Object, e As EventArgs)
    Dim message As String = String.Empty
    For Each item As ListItem In DropDownCheckBoxes1.Items
        If item.Selected Then
            message += item.Text + " " + item.Value + "\n"
        End If
    ClientScript.RegisterClientScriptBlock(Me.GetType(), "alert", "alert('" & message & "');", True)
End Sub
DropDownCheckBoxes: ASP.Net DropDownList CheckBoxList Server control
