In this article I will explain with an example, how to display Progress Indicator Bar in ASP.Net AJAX Control Toolkit AutoCompleteExtender Control.
Note: For more details on how to use ASP.Net AutoComplete Extender in ASP.Net, please refer Implement ASP.Net AJAX Control Toolkit AutoComplete Extender Extender.



Download and Install AJAX Control Toolkit

In order to download and install AJAXControlToolKit, please refer the following article.
Install AJAX Control Toolkit in Visual Studio ToolBoxToolBox



HTML Markup

The HTML Markup consists of following controls.
ScriptManager – Foe enabling ASP.Net AJAX.
TextBox – For Capturing Text.
AutoCompleteExtender – For enhances text input with suggestions dynamically.
<asp:ScriptManager ID="ScriptManager" runat="server"></asp:ScriptManager>
<asp:TextBox ID="txtContactsSearch" runat="server"></asp:TextBox>
<cc1:AutoCompleteExtender ServiceMethod="SearchCustomers" MinimumPrefixLength="2"
    CompletionInterval="100" EnableCaching="false" CompletionSetCount="10" TargetControlID="txtContactsSearch"
    ID="AutoCompleteExtender1" runat="server" FirstRowSelected="false" OnClientHiding="OnClientCompleted"
    OnClientPopulated="OnClientCompleted" OnClientPopulating="OnClientPopulating">
</cc1:AutoCompleteExtender>

Above I have added an ASP.Net AJAX AutoCompleteExtender with three client side events OnClientHiding, OnClientPopulated and OnClientPopulating. These events are used to display the loading GIF image when the call is made to search the records and also hides it when the records are populated. The client side methods called on these events are described below.
<script type="text/javascript">
    function OnClientPopulating(sender, e) {
        sender._element.className  = "loading";
    }
    function OnClientCompleted(sender, e) {
        sender._element.className  = "";
    }
</script>



Client Side Implementation

The OnClientPopulating JavaScript method gets called on the OnClientPopulating event handler and displays the loading GIF image by applying the “loading” CSS class to the TextBox control.
While the method OnClientCompleted gets called on the OnClientHiding and OnClientPopulated events and simply removes the CSS class so that the loading GIF image is hidden.



Loading GIF CSS Class

Below is the CSS that you need to add to your page in the HEAD section or CSS class in order to display the loading GIF image when the ASP.Net AJAX Control Toolkit AutoCompleteExtender fetches the records.
<style type="text/css">
    .loading
    {
        background-image:url(images/loader.gif);
        background-position:right;
        background-repeat:no-repeat;
    }
</style>



Screenshot

ASP.Net AJAX AutoCompleteExtender with Progress Indicator Bar
