In this article I will explain with an example, how to populate (bind) WebGrid using ADO.Net in ASP.Net MVC.



Database

I have made use of the following table Customers with the schema as follows.
Populate (Bind) WebGrid using ADO.Net in ASP.Net MVC

I have already inserted few records in the table.
Populate (Bind) WebGrid using ADO.Net in ASP.Net MVC

Note: You can download the database table SQL by clicking the download link below.
            Download SQL file



Namespaces

You will need to import the following namespaces.
using System.Data;
using System.Configuration;
using System.Data.SqlClient;



Controller

The Controller consists of following Action method.

Action method for handling GET operation

Inside this Action method, the records are fetched from the Customers Table of SQL Server database.
Finally, the object of DataSet is filled using Fill method of SqlDataAdapter and returned to the View.
Note: For more information on using SqlDataAdapter in ASP.Net MVC, please refer my article Implementing SqlDataAdapter in ASP.Net MVC.

public class HomeController : Controller
{
    // GET: Home
    public ActionResult Index()
    {
        DataSet ds = new DataSet();
        string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;
        string sql = "SELECT CustomerId, Name, Country FROM Customers";
        using (SqlConnection con = new SqlConnection(constr))
        {
            using (SqlCommand cmd = new SqlCommand(sql, con))
            {
                using (SqlDataAdapter sda = new SqlDataAdapter(cmd))
                {
                    sda.Fill(ds);
                }
            }
        }

        return View(ds);
    }
}



View

HTML Markup

Inside the View, the DataSet is declared as Model for the View.
The WebGrid is initialized with the Dynamic Anonymous Type collection by making use of LINQ i.e. the records from the DataTable are converted into Dynamic Anonymous Type collection and are assigned to the WebGrid.
The WebGrid is created using the GetHtml method with the following parameters.
HtmlAttributes – It is used to set the HTML attributes to the HTML Table generated by WebGrid such as ID, Name, Class, etc.
Columns – It is used to specify the columns to be displayed in WebGrid and also allows to set specific Header Text for the columns.
@using System.Data
@using System.Linq

@model DataSet
@{
    Layout = null;
    WebGrid webGrid = new WebGrid(source: (from p in Model.Tables[0].AsEnumerable()
                                           select new
                                           {
                                                CustomerId = p.Field<int>("CustomerId"),
                                                Name = p.Field<string>("Name"),
                                                Country = p.Field<string>("Country")
                                             }));
}

<!DOCTYPE html>

<html>
<head>
    <meta name="viewport" content="width=device-width" />
    <title>Index</title>
</head>
<body>
    @webGrid.GetHtml(
       htmlAttributes: new { @id = "WebGrid", @class = "Grid" },
       columns:webGrid.Columns(
                webGrid.Column("CustomerId", "Customer Id"),
                webGrid.Column("Name", "Name"),
                webGrid.Column("Country", "Country")))
</body>
</html>



CSS Class

The following CSS classes are used to styling the WebGrid.
<style type="text/css">
    body { font-family: Arial; font-size: 10pt; }
    .Grid { border: 1px solid #ccc; border-collapse: collapse; }
    .Grid th { background-color: #F7F7F7; font-weight: bold; }
    .Grid th, .Grid td { padding: 5px; border: 1px solid #ccc; }
    .Grid, .Grid table td { border: 0px solid #ccc; }
    .Grid th a, .Grid th a:visited { color: #333; }
</style>



Screenshot

Populate (Bind) WebGrid using ADO.Net in ASP.Net MVC



Downloads

Download Code
